304不锈钢脚轮

固定、活动、刹车

产品系列：S、MC、M、L、EM、ML、KPL、LX、Z系利

参考价格：面议

加入询盘篮询价

中山市蚂蚁金属制品有限公司

进入店铺收藏店铺联系客服

广东省

制造商

点击登录后查看

轻型系列安装数据
S-Series Light-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		丝杆尺寸 Stem Size	载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	丝杆尺寸 Stem Size	载重 Capacity Each	装箱数量 MPQ
1.5"	40mm	20mm	60mm	54*44mm	40*30mm	25mm	68±2mm	45.5±2mm	M10*25mm	30kg	120pcs
2"	50mm	22mm	70mm	54*44mm	40*30mm	22mm	68±2mm	45.5±2mm	M10*25mm	50kg	120pcs

MC款中型系列安装数据
MC-Series Medium-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		丝杆尺寸 Stem Size	载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	丝杆尺寸 Stem Size	载重 Capacity Each	装箱数量 MPQ
3"	75mm	32mm	105mm	95*64mm	74*45mm	33mm	108mm	72mm	M12*30mm	80kg	50pcs
4"	100mm	32mm	130mm	95*64mm	74*45mm	31.5mm	108mm	82mm	M12*30mm	110kg	50pcs
5"	125mm	32mm	155mm	95*64mm	74*45mm	30mm	108mm	93mm	M12*30mm	130kg	40pcs

中型系列安装数据
M-Series Medium-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		丝杆尺寸 Stem Size	载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	丝杆尺寸 Stem Size	载重 Capacity Each	装箱数量 MPQ
2.5"	64mm	32mm	95mm	95*70mm	75/72*52/45mm	31mm	106.5mm	65.5mm	M12*30mm	70kg	50pcs
3"	75mm	32mm	113mm	95*70mm	75/72*52/45mm	44.5mm	106.5mm	82mm	M12*30mm	80kg	50pcs
4"	100mm	32mm	137mm	95*70mm	75/72*52/45mm	45mm	107mm	95mm	M12*30mm	110kg	40pcs
5"	125mm	32mm	163mm	95*70mm	75/72*52/45mm	47.5mm	106.5mm	110mm	M12*30mm	130kg	30pcs

重型系列安装数据
L-Series Heavy-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	载重 Capacity Each	装箱数量 MPQ
4*2"	100mm	50mm	144mm	115*100mm	92/76*76/67mm	37mm	139mm	89mm	250kg	16pcs
5*2"	125mm	50mm	165mm	115*100mm	92/76*76/67mm	40mm	147mm	105mm	300kg	14pcs
6*2"	150mm	50mm	191mm	115*100mm	92/76*76/67mm	49mm	147mm	125mm	350kg	12pcs
8*2"	200mm	50mm	241mm	115*100mm	92/76*76/67mm	63mm	171mm	163mm	400kg	6pcs

中型减震系列安装数据 30KG起减震作用
Z-Series Spring-Loaded Medium-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		弹簧行程 Spring Distance	载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	弹簧行程 Spring Distance	载重 Capacity Each	装箱数量 MPQ
3"	75mm	32mm	113.5mm	95*70mm	75/72*52/45mm	80mm	152.5mm	117.5mm	10mm	70kg	50pcs
4"	100mm	32mm	138mm	95*70mm	75/72*52/45mm	83mm	165.5mm	134mm	12mm	100kg	40pcs
5"	125mm	32mm	163.5mm	95*70mm	75/72*52/45mm	81mm	175mm	145mm	16mm	120kg	30pcs

中重型系列安装数据
ML-Series Medium Heavy-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	载重 Capacity Each	装箱数量 MPQ
3*2"	75mm	42mm	105.5mm	97*85mm	75.6/68*66/58mm	24mm	112mm	64mm	180kg
4*2"	100mm	42mm	135.8mm	97*85mm	75.6/68*66/58mm	33.6mm	121mm	86mm	220kg
5*2"	125mm	42mm	158.5mm	97*85mm	75.6/68*66/58mm	37mm	130mm	102mm	250kg
6*2"	150mm	42mm	191mm	97*85mm	75.6/68*66/58mm	45mm	130mm	123mm	280kg

欧款系列安装数据
EM-Series European Medium-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	载重 Capacity Each	装箱数量 MPQ
3"	80mm	36mm	108mm	100*80mm	80/77*55/60mm	36mm	132mm	77mm	120kg
4"	100mm	36mm	125mm	100*80mm	80/77*55/60mm	34mm	133mm	85mm	150kg
5"	125mm	36mm	150mm	100*80mm	80/77*55/60mm	32.5mm	133mm	96mm	180kg
6"	150mm	36mm	185mm	100*80mm	80/77*55/60mm	38mm	133mm	113.5mm	250kg

抗冲击系列安装数据
KPL-Series Kingpinless Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius		载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	刹车支架 Swivel Fork With Brake	活动支架 Swivel Fork	载重 Capacity Each	装箱数量 MPQ
4*2"	100mm	50mm	144mm	115.5*110mm	92/76*76/67mm	22mm	132mm	77mm	450kg
5*2"	125mm	50mm	165mm	115.5*100mm	92/76*76/67mm	27mm	143mm	94mm	500kg
6*2"	150mm	50mm	191mm	115.5*100mm	92/76*76/67mm	36mm	145mm	115mm	650kg
8*2"	200mm	50mm	241mm	115.5*100mm	92/76*76/67mm	48mm	171mm	151mm	800kg

超重型系列安装数据
LX-Series Super Heavy-Duty Installation Spec.
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	旋转半径 Swivel Radius	载重 Capacity Each	装箱数量 MPQ
尺寸 Size	轮径 Wheel Diameter	轮宽 Wheel Width	安装高度 Load Height	底板尺寸 Top Plate Size	安装孔距 Bolt Hole Spacing	偏心距 Offset	活动支架 Swivel Fork	载重 Capacity Each	装箱数量 MPQ
6*3"	150mm	76mm	191mm	184*133mm	155/133*86/105mm	35mm	115mm	2000kg
8*3"	200mm	76mm	257mm	184*133mm	155/133*86/105mm	55.5mm	161mm	2500kg
10*3"	250mm	76mm	292mm	184*133mm	155/133*86/105mm	53.5mm	184mm	3000kg
12*3"	300mm	76mm	342.5mm	184*133mm	155/133*86/105mm	66mm	223mm	3500kg
