电烤箱
产品概述 Introduction
YXD-F30A 系列电热食品烤炉是采用不锈钢电热管为发热元件,加热速度快,被烤物品受热均匀,符合食品卫生标准,炉温可在20-300℃范围内任意调节,并能自动恒温,本产品设有定时,自动控温,手动控温等多种功能可供选择,操作方便。电烤炉采用分层各自控制结构,每一层的底火及面火均可以控制,本产品主要用于烘烤面包及饼食等。
性能特点 Features
1. Heating element is metal heating pipe, so heating is fast, baked items are heated evenly, taste excellent.
2. With timing, automatic temperature control, manual temperature control, automatic constant temperature and other more functions.
3. Each deck is indenpendently controlled, the bottom fire and surface fire in each layer can be controlled, so that the baking quality is ideal.
产品参数 Parameter
型号Model |
电压Voltage |
额定功率 Power |
温控范围 Temperature Range |
烤盘数量 Tray Qty |
烤盘尺寸 Tray Size |
外形尺寸Dimension |
YXD-F9A |
~220V/50Hz |
2.8kW |
室温Room Temp.~300°C |
1层1盘 |
400×600mm |
785×950×350mm |
YXD-F30A |
3N~380V/50Hz |
6.8kW |
室温Room Temp.~300°C |
1层2盘 |
400×600mm |
1240×920×400mm |
YXD-F60A |
3N~380V/50Hz |
13.6kW |
室温Room Temp.~300°C |
2层4盘 |
400×600mm |
1240×920×1230mm |
YXD-F90A |
3N~380V/50Hz |
20.4kW |
室温Room Temp.~300°C |
3层6盘 |
400×600mm |
1240×920×1630mm |
YXD-F120A |
3N~380V/50Hz |
27.2kW |
室温Room Temp.~300°C |
4层8盘 |
400×600mm |
1240×920×2190mm |
